| 型號 |
流量 M³/h |
揚程 m | 電機 功率 kw |
轉速 r/min |
型號 |
流量 M³/h |
揚程 m |
電機功率kw |
轉速 r/min |
| ISB50-32-160/1.1 | 6.3 | 18 | 1.1 | 2900 | ISB65-50-200/11 | 50 | 48 | 11 | 2900 |
| ISB50-32-160/1.5 | 12.5 | 20 | 1.5 | ISB65-50-200/15 | 50 | 58 | 15 | ||
| ISB50-32-160/2.2 | 12.5 | 25 | 2.2 | ISB65-50-200/18.5 | 50 | 68 | 18.5 | ||
| ISB50-32-200/3.0 | 12.5 | 32 | 3 | ISB80-65-125/5.5 | 100 | 13 | 5.5 | ||
| ISB50-32-200/4.0 | 12.5 | 42 | 4 | ISB80-65-125/7.5 | 100 | 18 | 7.5 | ||
| ISB50-32-200/5.5 | 12.5 | 54 | 5.5 | ISB80-65-125/11 | 100 | 23 | 9.2 | ||
| ISB65-40-125/1.5 | 25 | 13 | 1.5 | ISB80-65-160/11 | 100 | 27 | 11 | ||
| ISB65-40-125/2.2 | 25 | 18 | 2.2 | ISB80-65-160/15 | 100 | 36 | 15 | ||
| ISB65-40-125/3.0 | 25 | 24 | 3 | ISB80-65-200/18.5 | 100 | 45 | 18.5 | ||
| ISB65-40-160/4.0 | 25 | 28 | 4 | ISB80-65-200/22 | 100 | 53 | 22 | ||
| ISB65-40-200/5.5 | 25 | 36 | 5.5 | ISB80-65-200/30 | 100 | 66 | 30 | ||
| ISB65-40-200/7.5 | 25 | 46 | 7.5 | ISB100-80-160/11 | 160 | 15 | 11 | ||
| ISB65-40-200/11 | 25 | 62 | 11 | ISB100-80-160/15 | 160 | 22 | 15 | ||
| ISB65-50-125/3.0 | 50 | 13 | 3 | ISB100-80-160/18.5 | 160 | 28 | 18.5 | ||
| ISB65-50-125/4.0 | 50 | 18 | 4 | ISB100-80-200/22 | 160 | 33 | 22 | ||
| ISB65-50-160/5.5 | 50 | 25 | 5.5 | ISB100-80-200/30 | 160 | 45 | 30 | ||
| ISB65-50-200/7.5 | 50 | 32 | 7.5 | ISB100-80-200/37 | 160 | 54 | 37 | ||
| ISB65-50-200/11 | 50 | 40 | 11 |
